NEW QUESTION 1
Which type of Virtual Server requires the use of a FastL4 profile?

• A. Performance (Layer 4)
• B. Stateless
• C. Performance (HTTP)
• D. Standard

Answer: A

NEW QUESTION 2
Which parameters are set to the same value when a pair of BIG-IP devices are synchronized?

• A. host names
• B. system clocks
• C. profile definitions
• D. VLAN failsafe settings
• E. MAC masquerade addresses

Answer: C

NEW QUESTION 3
A site has assigned the ICMP monitor to all nodes and a custom monitor, based on the HTTP template, to a pool of web servers. The HTTP based monitor is working in all cases. The ICMP monitor is failing for 2 of the pool member 5 nodes. All other settings are default. What is the status of the monitor is working in all cases?

• A. All pool members are up since the HTTPbased monitor is successful.
• B. All pool members are down since the ICMPbased monitor is failing in some cases.
• C. The pool members whose nodes are failing the ICMPbased monitor will be marked disabled.
• D. The pool members whose nodes are failing the ICMPbased monitor will be marked unavailable.

Answer: D

NEW QUESTION 4
A BIG-IP Administrator reviews the log files to determine the cause of a recent problem and finds the following entry.
Mar 27.07.58.48 local/BIG-IP notice mcpd {5140} 010707275 Pool member 172.16.20.1.10029 monitor status down.
What is the cause of this log message?

• A. The pool member has been disabled.
• B. The pool member has been marked as Down by the BIG-IP Administrator.
• C. The monitor attached to the pool member needs a higher timeout value.
• D. The monitor attached to the pool member has failed.

Answer: D

NEW QUESTION 5
Which event is always triggered when a client initially connects to a virtual server configured with an HTTP profile?

• A. HTTP_DATA
• B. CLIENT_DATA
• C. HTTP_REQUEST
• D. CLIENT_ACCEPTED

Answer: D

NEW QUESTION 6
How should a BIG-IP Administrator control the amount of traffic that a newly enabled pool member receives.

• A. set the Slow Ramp Time
• B. set a Connection Limit
• C. set the Priority Group Activation
• D. set a Health Monitor

Answer: A

Explanation:
Slow Ramp Time
Specifies the duration during which the system sends less traffic to a newly-enabled pool member. The amount of traffic is based on the ratio of how long the pool member has been available compared to the slow ramp time, in seconds. Once the pool member has been online for a time greater than the slow ramp time, the pool member receives a full proportion of the incoming traffic. Slow ramp time is particularly useful for the least connections load balancing mode.
Setting this to a nonzero value can cause unexpected Priority Group behavior, such as load balancing to a low-priority member even with enough high-priority servers.

NEW QUESTION 7
What should the BIG-IP Administrator do to apply and activate a hotfix to a BIG-IP device that is currently running version 11.0.0 on active partition HD1.1?

• A. * 1. confirm that 11.0.0 is installed on inactive partition HD1.2* 2. apply a hotfix to partition HD 1.2* 3. activate partition HD1.2
• B. * 1. reactivate the license on partition HD1.1* 2. apply a hotfix to partition HD1.1
• C. * 1. activate partition HD1.2* 2 confirm version 11.0.0 on partition HD1.2* 3. install a hotfix on partition HD1.2
• D. * 1. set partition HD1.2 active* 2. apply a hotfix to partition HD1.2

Answer: A

NEW QUESTION 8
Refer to the exhibit. The BIG-IP Administrator needs to avoid overloading any of the Pool Members with connections, when they become active.
What should the BIG-IP Administrator configure to meet this requirement?

• A. Different Ratio for each member
• B. Same Priority Group to each member
• C. Action On Service Down to Reselect
• D. Slow Ramp Time to the Pool

Answer: D

NEW QUESTION 9
Given that VLAN failsafe is enabled on the external VLAN and the network that the active BIG-IP's external VLAN is connected to has failed, which statement is always true about the results?

• A. The active system will note the failure in the HA table.
• B. The active system will reboot and the standby system will go into active mode.
• C. The active system will failover and the standby system will go into active mode.
• D. The active system will restart the traffic management module to eliminate the possibility that BIG-IP is the cause for the network failure.

Answer: A

NEW QUESTION 10
Refer to the exhibit.

Which two pool members are eligible to receive new connections? (Choose two)

• A. 10.21.0.102.80
• B. 10.21.0.104.80
• C. 10.21.0.105.80
• D. 10.21.0.101.80
• E. 10.21.0.103.80

Answer: BD

NEW QUESTION 11
A BIG-IP Administrator wants to add the ASM Module to an HA pair of BIG-IP devices. The BIG-IP Administrator has already installed a new Add-On License on both devices in the HA pair. What should the BIG-IP Administrator do next to use the module?

• A. Provision the new module on both BIG-IP device's
• B. Synchronize both BIG-IP devices
• C. Reboot both BIG-IP devices
• D. Reactivate the Licenses on both BIG IP devices

Answer: A

NEW QUESTION 12
The BIG-IP Administrator needs to perform a BIG-IP device upgrade to the latest version of TMOS. Where can the administrator obtain F5 documentation on upgrade requirements?

• A. AskF5
• B. DevCentral
• C. Bug Tracker
• D. iHealth

Answer: A

NEW QUESTION 13
Which statement accurately describes the difference between two loadbalancing modes specified as "member" and "node"?

• A. There is no difference; the two terms are referenced for backward compatibility purposes.
• B. When the loadbalancing choice references "node", priority group activation is unavailable.
• C. Loadbalancing options referencing "nodes" are available only when the pool members are defined for the "any" port.
• D. When the loadbalancing choice references "node", the addresses' parameters are used to make the loadbalancing choice rather than the member's parameters.

Answer: B

NEW QUESTION 14
A BIG-IP Administrator must determine if a Virtual Address is configured to fail over to the standby member of a device group in which area of the Configuration Utility can this be confirmed?

• A. Device Management > Traffic Groups
• B. Device Management > Devices
• C. Local Traffic > Virtual Servers
• D. Device Management > Overview

Answer: C

NEW QUESTION 15
A BIG-IP Administrator applied the latest hotfix to an inactive boot location by mistake, and needs to downgrade back to the previous hotfix.
What should the BIG-IP Administrator do to change the boot location to the previous hotfix?

• A. Uninstall the newest hotfix and reinstall the previous hotfix
• B. Reinstall the base version and install the previous hotfix
• C. Reinstall the previous hotfix and re-activate the license
• D. Uninstall the base version and restore the UCS

Answer: B
